bezel material |
Chromium plated metal |
mounting diameter |
22 mm |
product compatibility |
Ø 6 mm shaft |
sale per indivisible quantity |
1 |
CAD overall width |
30 mm |
CAD overall height |
47 mm |
CAD overall depth |
82 mm |
Net weight |
0.095 kg |
protective treatment |
TH |
Ambient air temperature for storage |
-40…70 °C |
Ambient air temperature for operation |
-40…70 °C |
electrical shock protection class |
Class II conforming to IEC 60536 |
IP degree of protection |
IP66 conforming to IEC 60529 IP69 conforming to IEC 60529 IP69K conforming to IEC 60529 |
NEMA degree of protection |
NEMA 13 NEMA 4X |
resistance to high pressure washer |
7000000 Pa at 55 °C, distance : 0.1 m |
IK degree of protection |
IK06 conforming to IEC 50102 |
Standards |
UL 508 EN/IEC 60947-1 CSA C22.2 No 14 |
product certifications |
CSA BV UL listed |
shape of signaling unit head |
Round |
operator profile |
Knurled knob, with (white) |
[Us] rated supply voltage |
<= 30 V AC <= 42 V DC |
rated power in W |
1 W at 70 °C |
precision of internal conversion resistor |
+-10% |
potentiometer characteristic |
Linear |
mechanical durability |
50000 cycles |
ohmic value |
10000 Ohm |
material |
Cermet |
vibration resistance |
5 gn (f= 2…500 Hz) conforming to IEC 60068-2-6 |
shock resistance |
30 gn (duration = 18 ms) for half sine wave acceleration conforming to IEC 60068-2-27 50 gn (duration = 11 ms) for half sine wave acceleration conforming to IEC 60068-2-27 |
main group |
Potentiometer |
group of product |
Potentiometer knurled knob |
colour of marking |
White |
