SGT 14-280-056-A1-A-01-5 TELCO SENSORS Self-Contained Light Curtains Light Curtains

SGT 14-280-056-A1-A-01-5 Self-Contained Light Curtains Light Curtains

Be the first to review this product

SKU: PCM1364

Old price: 3,950.00 (SAR)

Price: 3,781.00 (SAR)

Qty: GET A QUOTE FOR THIS

Why to Shop at faakart.com

Standard Delivery*

We provide standard delivery across the country.
Return Policy*

We provide transparent return and exchange policy, please refer to terms and conditions for details.
100% Genuine Products

We do not sell anything which is counterfeited or tampered-with in manner, so you can be at ease that purchased product is 100% genuine.

Product Data

Operation Mode	Thru Beam
Function	Transmitter
Supply Voltage	12 - 36 V dc
Active Height	2535 mm
Number of Channels	56
Sensing Range	10 m
Housing	10 x 28 mm
Length	2800 mm
Connection	5 m cable

Technical Data

Supply Voltage	12 – 36 V dc
Reverse Polarity Protected	Yes
Current Consumption	70 mA
Spacing between bottom & Ch1	25 mm
Channel Spacing	46 mm
Test Input	Yes
Power On Indicator	Green LED
Min. / Max. Sequencial Blanking Speed	1,6 m/s / 0,05 m/s
Light Source	Infrared (880 nm)
Profile Dimensions (w x d)	Slim Line (A), 10 x 28 mm
Housing Material, Front Lens	Polycarbonate
Housing Material, Profile	Aluminium (black anodised)
Cable	3 x 0,20 mm²
Cable Sleeve	PVC Ø 4,9 mm

Environmental Data

Operation Temperature	–20 to +65 °C
Storage Temperature	–40 to +80 °C
Sealing Class	IP 54
Light Immunity 5˚	> 100 000 lux
