LVS04031 SCHNEIDER LINERGY DX 1P DIST.BLOCK 160A 4M 6HOLES

LINERGY DX 1P DIST.BLOCK 160A 4M 6HOLES LVS04031

Be the first to review this product

Manufacturer: Schneider

SKU: AELR15260316

Old price: 152.00 (SAR)

Price: 98.00 (SAR)

Qty: GET A QUOTE FOR THIS

Why to Shop at faakart.com

Standard Delivery*

We provide standard delivery across the country.
Return Policy*

We provide transparent return and exchange policy, please refer to terms and conditions for details.
100% Genuine Products

We do not sell anything which is counterfeited or tampered-with in manner, so you can be at ease that purchased product is 100% genuine.

Specifications

Main
Range	Linergy
Range of product	Linergy
Product or component type	Distribution block
Product name	Linergy DX
Range compatibility	PrismaSeT PrismaSeT G enclosure PrismaSeT PrismaSeT P enclosure PrismaSeT Prisma PH enclosure PrismaSeT PrismaSeT Pack 250 enclosure
Product compatibility	Spacial enclosures
Accessory / separate part category	Current distribution accessory
IP degree of protection	IPxx B

Complementary
Mounting support	DIN rail
Installed device	Acti 9: fixed C120 with earth leakage protection - control: toggle Acti 9: fixed C120 without earth leakage protection - control: toggle Acti 9: fixed iC120 with earth leakage protection - control: toggle Acti 9: fixed iC120 without earth leakage protection - control: toggle ComPact: fixed INS40 - control: direct front rotary handle - vertical installation ComPact: fixed INS63 - control: direct front rotary handle - vertical installation ComPact: fixed INS100 - control: direct front rotary handle - vertical installation ComPact: fixed INS125 - control: direct front rotary handle - vertical installation ComPact: fixed INS160 - control: direct front rotary handle - vertical installation FuPact: fixed ISFT160 - control: fuse carriers handle - vertical installation FuPact: fixed ISFT100N - control: fuse carriers handle - vertical installation Multi9: fixed NG125 with earth leakage protection - control: toggle Multi9: fixed NG125 without earth leakage protection - control: toggle Multi9: fixed NG125 NA - control: toggle ComPact: fixed NG160 with earth leakage protection - control: toggle ComPact: fixed NG160 without earth leakage protection - control: toggle ComPact: fixed NG160 NA without earth leakage protection - control: toggle FuPact: fixed INF100...160 - control: extended rotary handle - vertical installation ComPact: fixed NSXm without earth leakage protection - control: toggle - vertical installation ComPact: fixed NSXm without earth leakage protection - control: toggle - horizontal installation ComPact: fixed NSXm without earth leakage protection - control: direct rotary handle - horizontal installation ComPact: fixed NSXm with earth leakage protection - control: toggle - vertical installation ComPact: fixed NSXm with earth leakage protection - control: toggle - horizontal installation
Poles description	1P
[Ue] rated operational voltage	690 V AC
[Ui] rated insulation voltage	750 V AC
[Uimp] rated impulse withstand voltage	8 kV
[Ie] rated operational current	160 A
[In] rated current	160 A at 40 °C
[Icw] rated short-time withstand current	5.5 kA for 1 s
[Ipk] rated peak withstand current	24 kA
I²t on activation	30250000 A².s
Connections - terminals	Supply: tunnel type terminal70 mm² (flexible) Supply: tunnel type terminal70 mm² (rigid) Distribution: spring terminal, 6 x 6…16 mm² (flexible) Distribution: spring terminal, 6 x 6…16 mm² (rigid)
9 mm pitches	4
Total number of 18 mm modules	2
Height	95 mm
Width	36 mm
Depth	70 mm
Net weight	0.1 kg
Colour	Anthracite grey (RAL 7016)

Environment
Pollution degree	3
Resistance to incandescent wire	960 °C conforming to IEC 60695-2-11
Standards	IEC 61439-1, inside enclosure IEC 61439-2, inside enclosure IEC 60947-7-1
Product certifications	ASTA

Packing Units
Unit Type of Package 1	PCE
Number of Units in Package 1	1
Package 1 Height	3.600 cm
Package 1 Width	5.600 cm
Package 1 Length	11.200 cm
Package 1 Weight	152.000 g
Unit Type of Package 2	BB1
Number of Units in Package 2	12
Package 2 Height	12.500 cm
Package 2 Width	5.300 cm
Package 2 Length	44.500 cm
Package 2 Weight	1.890 kg
Unit Type of Package 3	CAR
Number of Units in Package 3	60
Package 3 Height	12.500 cm
Package 3 Width	27.800 cm
Package 3 Length	44.500 cm
Package 3 Weight	9.520 kg
