Picture of LC1G500KUEN SCHNEIDER High power contactor

LC1G500KUEN SCHNEIDER High power contactor

High power contactor, TeSys Giga, 3 pole (3NO), AC-3 <=440V 500A, standard version, 100…250V wide band AC/DC coil
Be the first to review this product
Manufacturer: Schneider
SKU: NSRN1752
6,899.00 (SAR)
6,217.00 (SAR)
GET A QUOTE FOR THIS

Why to Shop at faakart.com

  • Standard Delivery*

    We provide standard delivery across the country.

  • Return Policy*

    We provide transparent return and exchange policy, please refer to terms and conditions for details.

  • 100% Genuine Products

    We do not sell anything which is counterfeited or tampered-with in manner, so you can be at ease that purchased product is 100% genuine.

Description

TeSys Giga high-power contactor, 3 poles (3 NO) for category AC-3 applications up to 500A (315kW) at 440V. It provides a 100-250V AC/DC wide-band low-consumption electronic coil and an embedded highly reliable 1NO+1NC auxiliary contact block (17V, 1 mA). Designed for demanding applications with maximum operating rates of up to 600 cycles per hour and environments up to 60 °C,. It procures high reliability and durability with 5-cycle mechanical durability. Local Contact Wear Diagnosis (CWD) is a standard function of continuous monitoring with healthy and alarm indicators. It is possible to replace the switching module (main contacts) and enhance the life of the contactor. The contactor can be fixed in all quadrants without removing cables/busbars, and the OLR could be directly mounted below the contactor. To be used with power connections by bolted connection and control connections by spring terminals, accessible from the front for easy and quick replacement. It provides IP2x protection on the front face with shrouds conforming to IEC 60529 and VDE 0106. It can cover -25°C to 60°C operation ambient air temperature and directly mounted on plate, No derating up to 3000m altitude. The dimensions are 290mm x 140mm x 209mm (H x W x D). This compact size enables panel space savings. Multi-standards certified (CE,CB,CCC,cULus,EAC,KC, RCM, and Marine) and Green Premium compliant (RoHs/Reach).
