BMXAMO0410 SCHNEIDER isolated analog output module X80

Why to Shop at faakart.com

We provide standard delivery across the country.

We provide transparent return and exchange policy, please refer to terms and conditions for details.

We do not sell anything which is counterfeited or tampered-with in manner, so you can be at ease that purchased product is 100% genuine.

Measurement error : 0.1 % of full scale 25 °C
Temperature drift : 45 ppm/°C +/- 10 V45 ppm/°C 0...20 mA45 ppm/°C 4...20 mA
Minimum crosstalk attenuation : 80 dB
Common mode rejection : 100 dB
Isolation voltage : 1400 V DC between channels and ground1400 V DC between channels and bus750 V DC between channels
Detection type : Open circuit 0...20 mAOpen circuit 4...20 mAShort circuit +/- 10 V
Load impedance ohmic : >= 1000 Ohm +/- 10 V
Output level : High level
Analogue output number : 4
Analogue output type : Current: 0...20 mACurrent: 4...20 mAVoltage: +/- 10 V
Analogue output resolution : 15 bits + sign
Supply : Internal power supply via rack
Conversion time :
Maximum conversion value : 0...21 mA 0...20 mA0...21 mA 4...20 mA+/- 10.5 V +/- 10 V
Fallback mode : ConfigurablePredefined
Operating altitude : 0...2000 m2000...5000 m with derating factor
Status LED : 1 LED (green)RUN1 LED per channel (green)channel diagnostic1 LED (red)ERR1 LED (red)I/O
Product weight : 0.15 kg
Power consumption in W : 3 W 24 V DC typical3.6 W 24 V DC maximum0.45 W 3.3 V DC typical0.51 W 3.3 V DC maximum

Additional information

Vibration resistance : 3 gn
Shock resistance : 30 gn
Ambient air temperature for storage : -40...85 °C
Ambient air temperature for operation : 0...60 °C
Relative humidity : 5...95 % at 55 °C without condensation
IP degree of protection : IP20
Directives : 2014/35/EU - low voltage directive2014/30/EU - electromagnetic compatibility
Product certifications : CERCMCSAEACMerchant NavyUL
Standards : EN/IEC 61010-2-201EN/IEC 61131-2UL 61010-2-201CSA C22.2 No 61010-2-201
