BI30R-W30-DAP6X-H1141 TURCK Inductive Ring-Style Proximity Sensor

Rectangular, height 30 mm Plastic, PA12‐GF30 Pulse duration: 100 ms Sensitivity adjusted via potentiometer DC 3-wire, 10…30 VDC Dynamic output behaviour NO contact, PNP output M12 x 1 male connector
Manufacturer: TURCK
SKU: NSRN1397
1,500.00 (SAR)
831.00 (SAR)
GET A QUOTE FOR THIS

Why to Shop at faakart.com

  • Standard Delivery*

    We provide standard delivery across the country.

  • Return Policy*

    We provide transparent return and exchange policy, please refer to terms and conditions for details.

  • 100% Genuine Products

    We do not sell anything which is counterfeited or tampered-with in manner, so you can be at ease that purchased product is 100% genuine.

Brand

Turck

Sensor Technology

Inductive

Body Style

Ring

Output Type

PNP

Detection Range

30 mm

Terminal Type

4-Pin M12 Connector

IP Rating

IP67

Supply Voltage

10 → 30 V dc

Length

60mm

Width

35mm

Depth

30mm

Maximum dc Voltage

30V

Mounting Type

Flush

Switching Current

200 mA

Shielding

Shielded

Maximum Switching Frequency

8Hz

Housing Material

Polyamide

Maximum Operating Temperature

+70°C

Minimum Operating Temperature

-25°C

Reverse Polarity Protection

Yes

Short Circuit Overload Protection

Yes
