Picture of 8025175 FESTO Profile cylinder and tie rod cylinder

8025175 FESTO Profile cylinder and tie rod cylinder

Pneumatic connection G3/4 Stroke 1mm Operating Pressure 0,6 bar ... 10 bar Mounting Position optional Weight 15,493g
Be the first to review this product
Manufacturer: Festo
SKU: NSRN187
3,000.00 (SAR)
2,633.00 (SAR)
GET A QUOTE FOR THIS

Why to Shop at faakart.com

  • Standard Delivery*

    We provide standard delivery across the country.

  • Return Policy*

    We provide transparent return and exchange policy, please refer to terms and conditions for details.

  • 100% Genuine Products

    We do not sell anything which is counterfeited or tampered-with in manner, so you can be at ease that purchased product is 100% genuine.

Material swivel mounting   Painted spheroidal graphite cast iron
Material tie rod   High-alloy steel High-alloy stainless steel
Material bearing   Bronze Metal polymer compound
Material nut   Galvanised steel High-alloy stainless steel
Cushioning piston material   Wrought aluminium alloy POM
Material piston rod wiper   FPM NBR
Material piston   Cast aluminium
Material cover   Cast aluminium, coated
Pneumatic connection   G3/4
Basic weight for 0 mm stroke   15.493 g
Moving mass for 0 mm stroke   5.348 g
Theoretical force at 0.6 MPa (6 bar, 87 psi), return stroke   18.096 N
Ambient temperature   -20 °C ... 150 °C
Note on operating and pilot medium   Lubricated operation possible (in which case lubricated operation will always be required)
Explosion ambient temperature   -20°C <= Ta <= +60°C
Explosion ignition protection type for gas   c T4
ATEX category gas   II 2G
CE mark (see declaration of conformity)   To EU Explosion Protection Directive (ATEX)
Operating pressure   0,6 bar ... 10 bar
Symbol   00991217 00991218 00991235 00991237
Design   Piston Piston rod Tie rod Cylinder barrel
Conforms to standard   ISO 15552
Cushioning   Elastic cushioning rings/plates at both ends Pneumatic cushioning, adjustable at both ends
Piston rod thread   M20 M20x1.5 M24 M27 M27x2 M30x2 M36 M36x2
Stroke   1 mm ... 2.700 mm
Material spacer bolt   High-alloy steel High-alloy stainless steel
Material collar nut   Galvanised steel
Material rod wiper   Brass
Material cylinder barrel   Smooth-anodised wrought aluminium alloy
Buffer seal material   FPM TPE-U(PU)
Material piston rod   High-alloy stainless steel, hard chrome-plated High-alloy steel High-alloy stainless steel
Material piston seal   FPM NBR
Note on materials   Contains paint-wetting impairment substances RoHS-compliant
Additional weight per 10 mm stroke   97 g
Additional moving mass per 10 mm stroke   249 g
Theoretical force at 0.6 MPa (6 bar, 87 psi), advance stroke   18.850 N
Cushioning length   48 mm
Corrosion resistance class CRC   2 - Moderate corrosion stress 3 - high corrosion stress
Operating medium   Compressed air to ISO 8573-1:2010 [7:4:4]
Explosion ignition protection type for dust   c T120°C
ATEX category dust   II 2D
Explosion protection   Zone 1 (ATEX) Zone 2 (ATEX) Zone 21 (ATEX) Zone 22 (ATEX)
Mode of operation   Double-acting
Variants   Extended male piston rod thread Piston rod with female thread Custom thread on the piston rod Extended piston rod Metal scraper High corrosion protection Through piston rod Heat-resistant seals max. 120°C Clamped swivel mounting position Screwed-on swivel mounting position Spacer bolt on end cap side Spacer bolt on both sides Spacer bolt on bearing cap side Variable spacer bolt length Temperature range 0 to 150°C Shortened male piston rod thread Piston rod at one end For proximity switch
Position detection   Via proximity switch
Piston-rod end   Male thread Female thread
Mounting position   optional
Based on standard   ISO 15552
Piston diameter   200 mm
