Picture of 60N2L063A0100 CAMOZZI Double acting Aircylinder

60N2L063A0100 CAMOZZI Double acting Aircylinder

60N2L063A0100 Single and double-acting, magnetic cushioned Ф 32, 40, 50, 63, 80, 100,125 , A permanent magnet, mounted on the piston, enables information to be received regarding the piston position by means of proximity switches positioned along the cylinder tube. This cylinders series is normally equipped with adjustable end-stroke cushioning. Moreover these cylinders are equipped with a mechanical cushioning in order to reduce the impact of the piston as it reaches the end of the stroke.
Be the first to review this product
Manufacturer: CAMOZZI
SKU: SHA4004
650.00 (SAR)
570.00 (SAR)
GET A QUOTE FOR THIS

Why to Shop at faakart.com

  • Standard Delivery*

    We provide standard delivery across the country.

  • Return Policy*

    We provide transparent return and exchange policy, please refer to terms and conditions for details.

  • 100% Genuine Products

    We do not sell anything which is counterfeited or tampered-with in manner, so you can be at ease that purchased product is 100% genuine.

Technical parameters

Bore
Ф 63
Cushioning
adjustable end-stroke cushioning, font 17 mm, rear 16 mm (option - wtihout cushioning )
Type of construction
with tie-rods
Function / operation
double-acting, single-acting, tandem
Materials
aluminium end-blocks, NBR seals, PU rod, other parts see coding
Mounting
with tie-rods, front flange, rear flange, feet, centre trunnion, front and rear trunnion, swivel combination
Stroke
10-2500 mm
Operating temperarure
0°C .. +80°C (with dry air min -20°C, wiht optional FKM seals up to +130°C)
Operating pressure
1 .. 10 bar
Speed
10 .. 1000 mm/sec (without load)
Fluid
filtered air, without lubricant; if lubricated air is used, it is recommanded to use ISOVG32 oil. Once applied the lubrication should never be interrupted.
Item Description
Cylinder series 60
magnet for proximity sensors in piston
60M -mangetic; 60N- non magnetic
