The Siemens 3TF54 is a
3-phase IEC rated contactor
used for the control of electric
motors. It is rated 100 HP at
230V and 200 HP at 460V.
Conforms to IEC 60946
Description
TeSys GV motor circuit breaker, 3 poles (3P), 6.3A/690V, for 3-phase motor applications, 2.2kW@400V. It provides thermal-magnetic protection with a thermal setting range of 4-6.3A, magnetic tripping at 13xIn, and a high breaking capacity of ICU 100kA at 400V. Connection by screw-clamp terminals. Start-stop control by rotary knob is guaranteed for 100,000 cycles of AC-3. Multi-standards certified (IEC, UL, CSA, CCC, EAC, Marine, ATEX), green premium compliant (RoHS/REACH).
