3-way signal conditioner with plug-in connection technology and calibrated measuring range changeover for the electrical isolation of unipolar and bipolar analog signals. Input/output is configurable via a DIP switch. push-in connection technology, standard configuration.
Design: Diaphragm valve
Valve function: 2/2-way, closed, monostable
Connection Process valve: G1
Standard nominal flow rate (standardised to DIN 1343):
11500 l/min
Medium pressure: 0.5 bar - 10 bar
Pneumatic connection, port 1: G1/4
Standard nominal flow rate (standardised to DIN 1343): 1500 l/min
Pressure regulation range: 0.5 bar - 12 bar
Grade of filtration : 40 µm
MS4-LR-1/4-D6-VS-DM2
Pneumatic connection 1
G1/4
Standard nominal flow rate
1800 l/min
Pressure regulation range
0.3 bar - 7 bar
Max. pressure hysteresis
0.4 bar
