Mode of operation: Double-acting
Piston diameter: 125 mm
Theoretical force at 0.6 MPa (6 bar, 87 psi), advance stroke: 7363 N
Stroke: 1 mm - 2800 mm
Cushioning: Pneumatic cushioning, adjustable at both ends
DSNU1055PA
PNEUMATIC ROUND CYLINDER
DOUBLE ACTING
10 MM PISTON DIAMETER
55 MM STROKE
ELASTIC CUSHIONING RINGS/PLATES ON BOTH SIDES
FOR PROXIMITY SENSOR
STANDARD END CAP
ONE END ROD TYPE
Mode of operation: Double-acting
Piston diameter: 32 mm
Theoretical force at 0.6 MPa (6 bar, 87 psi), advance stroke
: 482.5 N
Stroke: 250 mm
Cushioning : Self-adjusting pneumatic end-position cushioning
Round cylinder DSNU-40-200-P-A For position sensing, with elastic cushioning rings in end positions. Various mounting options, with or without additional mounting components. Stroke=200 mm, Piston diameter=40 mm, Piston rod thread=M12x1,25, Cushioning=P: Flexible cushioning rings/plates at both ends, Assembly position=Any
