DVU-32-125-A-P-A
COMPACT CYLINDER
DOUBLE-ACTING
NO PROTECTION AGAINST ROTATION
32 MM PISTON DIAMETER
125 MM STROKE
MALE THREAD
ELASTIC CUSHIONING RINGS
POSITIONING VIA PROXIMITY SENSOR
SINGLE ENDED PISTON ROD
STANDARD LATERAL FORCE
Mode of operation
Double-acting
Piston diameter
32 mm
Theoretical force at 0.6 MPa (6 bar, 87 psi), advance stroke
483 N
Stroke
15 mm
Cushioning
Elastic cushioning rings/plates at both ends
Mode of operation
Double-acting
Piston diameter
32 mm
Theoretical force at 0.6 MPa (6 bar, 87 psi), advance stroke
483 N
Stroke
25 mm
Cushioning
Elastic cushioning rings/plates at both ends
Mode of operation: Double-acting
Piston diameter: 40 mm
Theoretical force at 0.6 MPa (6 bar, 87 psi), advance stroke: 754 N
Stroke 40 mm
Cushioning: Elastic cushioning rings/plates at both ends
Mode of operation: Double-acting
Piston diameter: 80 mm
Theoretical force at 0.6 MPa (6 bar, 87 psi), advance stroke 3016 N
Stroke 20 mm
Cushioning: Elastic cushioning rings/plates at both ends
Series AF modular style air filter is a cost effective, clean looking solution to your filtration needs. Its' modular design allows connection with other SMC air preparation equipment. The series is available in six size options with a wide range of accessories.
2 different body sizes
Variety of different drain options
Aluminum die cast body
